Stahl Offset Antenna (Ø 40 cm)
Stahl Offset Antenna (Ø 40 cm)
Stahl Offset Antenna (Ø 40 cm)

Stahl Offset Antenna (Ø 40 cm)

SKU SPI440.0

€32,49
  • Mast bracket with hex nuts
  • Can be combined with all SCHWAIGER LNBs
Auf Lager

Sichere Zahlung

Apple Pay Bancontact BLIK EPS Google Pay iDEAL Wero Klarna Maestro Mastercard MobilePay PayPal Shop Pay Union Pay Visa

Passend dazu
Produktbeschreibung

With this SCHWAIGER® offset antenna, all free and encrypted television and radio programs can be received via satellite. Thanks to the special material processing, this offset antenna has a long service life and is, for example, ideal for use in the garden.

Technische Daten
Reflector (width) 424 mm
Reflector (height) 424 mm
Frequency range 10.7 - 12.75 GHz
Feed intake 40 - 40 mm
Material reflector Powder-coated steel
Material back part plastic
Material mast holder Galvanized steel
Material LNB bracket plastic
Material LNB support arm aluminum
Antenna gain (max.) 32.6 dB
Wind load 150 N (EN 60728-11)
Elevation setting range 5-48 °
Offset angle 25 °
Half width 5 °
Mast clamp clamping range 32-60 mm
colour Light gray (RAL7035)
scope of delivery Steel mirror, mast bracket, mounting material
